Fusion Signature Series 3i - 8.8

Fusion Signature Series 3i - 8.8" 330-watt CRGBW Sports Black Marine Wake Tower

Part Number 010-02773-51

BUY NOW

Feature
Specs
In The Box
Update
Accessories

MADE FOR LIFE ON THE WATER, JUST LIKE YOU

Bring on the action. The Signature Series 3i wake tower speakers produce premium sound that cuts through the air and elevates your activity.

Enjoy premium sound, specifically optimized for wake boats.

The marinized design has an IP65 rating.

Multiple mounting accessories are available.

These speakers are available in 6.5” and 8.8” designs with sports style grilles.

CRGBW LED lights set the scene on your boat.

Built to last season after season, the Signature Series 3i wake tower speakers include a supported 3-year warranty.

ENGINEERED FOR THE WAKE

Designed specifically for wake boat applications, these speakers have a precisely calculated enclosure for high quality audio reproduction at any volume level.

MARINIZED DESIGN

An improved mechanical and material design delivers superior protection from the harsh marine environment, season after season.

TRUE-MARINE PHILOSOPHY

Any product that bears the Fusion True-Marine seal of assurance has been designed by Fusion to withstand the harshest marine environments season after season and comes with an industry-leading 3-year warranty.

CURV CONE TECHNOLOGY

A lighter and stronger woven fiber composit produces greater sound definition at a higher volume.

LED ILLUMINATION

Cool white, red, green, blue, warm white. You can choose and mix colors to match the mood of your music.

SYSTEM INTEGRATION

These speakers are designed to work optimally with Fusion stereo systems and amplifiers (sold separately) with custom DSP profiles. This requires the Fusion Audio smart-device app for setup.

DESIGNED TO SUIT YOUR BOAT

Available in 6.5” and 8.8” sizes in sports white or sports black. The 6.5” speakers feature redesigned enclosures and mounting bracket systems.

Superior sound quality with Fusion DSP and Apollo Series.

Learn More

Experience the difference between hearing the music and feeling it with Fusion Apollo marine amplifiers.

Learn More

Amplify the atmosphere with the Fusion speaker lighting remote.

Learn More

General
Warranty	3 years
Sizes	6.5"/8.8"
Color	Sports White or Sports Black
Physical dimensions (Diameter)	6.5": 6.93" (176 mm) 8.8": 8.82" (224 mm)
Physical dimensions (Depth)	6.5": 9.21" (234 mm) 8.8": 15.16" (385 mm)
Weight	6.5": 4.7 lbs (2.13 kg) 8.8": 9.9 lbs (4.5 kg)
Water and dust rating	IP65
Speaker type	Coaxial
Continuous power handling (RMS)	6.5": 75 W 8.8": 130 W
Sensitivity (SPL @ 1 W/1 m)	6.5": 90 dB 8.8": 91 dB
Frequency response (+/- 3 dB)	6.5": 70 Hz-22 kHz 8.8": 50 Hz-20 kHz
Nominal impedance	4 Ω
LED lighting	yes - CRGBW
LED supply voltage	10.8-16 VDC
LED Load Current @ 14.4 VDC (max)	300 mA
Operating temperature range	32° to 122° F (0° to 50° C)
Cone material	CURV® Cone Technology with Rubber Surround
Tweeter type	Silk Dome
Electrical Features
Compass safe distance	6.5": 122" (310 cm) 8.8": 162" (412 cm)
Networking & Connections
Speaker connections	Spade Connectors
LED connection	Bullet Connectors

General
Physical dimensions (Diameter x Depth)	6.5" wake tower speaker: 6.93" x 9.21" (176 x 234 mm)
Physical dimensions (Diameter x Depth)	8.8" wake tower speaker: 8.82" x 15.16" (224 x 385 mm)
Weight (single unit)	6.5" wake tower speaker: 4.7 lbs (2.13 kg)
Weight (single unit)	8.8" wake tower speaker: 9.9 lbs (4.5 kg)
Water and dust rating	IP65
Configuration	Coaxial
Peak power (watts)	6.5" wake tower speaker: 230 watts
Peak power (watts)	8.8" wake tower speaker: 330 watts
RMS power rating (watts)	6.5" wake tower speaker: 75 watts
RMS power rating (watts)	8.8" wake tower speaker: 130 watts
Sensitivity (1 watt @ 1 meter)	6.5" wake tower speaker: 90 dB
Sensitivity (1 watt @ 1 meter)	8.8" wake tower speaker: 91 dB
Frequency response	6.5" wake tower speaker: 70 Hz–22 kHz
Frequency response	8.8" wake tower speaker: 50 Hz–20 kHz
Nominal impedance	4 ohm
Recommended amplifier power (watts RMS)	6.5" wake tower speaker: 30–90 watts/channel
Recommended amplifier power (watts RMS)	8.8" wake tower speaker: 25–140 watts/channel
LED lighting	yes, CRGBW
LED supply voltage	10.8–16 VDC
LED load current @14.4 VDC (max)	300 mA
Operating temperature range	32–122 degrees F (0–50 degrees C)
Voice coil diameter	6.5" wake tower speaker: 1.2"
Voice coil diameter	8.8" wake tower speaker: 1.5"
Cone material	CURV® Cone Technology with rubber surround
Tweeter type	Silk dome
Compass-safe distance	6.5" wake tower speaker: 122" (310 cm)
Compass-safe distance	8.8" wake tower speaker: 162" (412 cm)
Warranty	3 years

One pair of wake tower speakers (based on what you select)
